End Mills / 180CB

Solid Carbide TuffCut® XR7, 7 Flute End Mill, Series 180CB
Chipbreaker prolongs tool life by reducing re-cutting of chips, and creates shorter chips that can be evacuated more easily.
  • 7 Flute
  • Solid carbide
  • Cutting forces minimized resulting in straighter walls on long axial engagements
  • Higher feed rates
  • Chatter reduced or eliminated
  • ALtima® Blazed coated, B=ALtima® Blaze coated
  • Long and X-long flute lengths
  • 38° helix
  • For roughing and finishing with a chipbreaker application
  • Non-center cutting
  • Square end and corner radius options
  • Corner radius option will provide a stronger corner for less wear during roughing or finishing

Materials

  • Steel
  • Stainless steel
  • Super-alloys and titanium

Applications

  • High Efficiency Milling

Series Attributes

Downloads

Product Range

Tool No. EDP Diameter (D/D1) Shank Diameter (D2) Overall Length (L1) Flute Length (L2) Neck Length (L3) Corner Radius Coating Shank Type Available List Price
.2500 180L2500B 18904 1/4 1/4 3 1-1/4 ALtima® Blaze Straight 100.00 79.67
.2500 180X2500B 18906 1/4 1/4 4 1-3/4 ALtima® Blaze Straight 16.00 86.59
.2500 180L2504B 18913 1/4 1/4 3 1-1/4 0.03 ALtima® Blaze Straight 48.00 87.64
.2500 180X2504B 18915 1/4 1/4 4 1-3/4 0.03 ALtima® Blaze Straight 21.00 95.26
.3750 180L3750B 18912 3/8 3/8 4 1-1/2 ALtima® Blaze Straight 125.00 111.49
.3750 180X3750B 18914 3/8 3/8 4 2-1/2 ALtima® Blaze Straight 6.00 126.41
.3750 180L3750BW 14819 3/8 3/8 4 1-1/2 ALtima® Blaze Weldon 18.00 115.44
.3750 180L3754B 18917 3/8 3/8 4 1-1/2 0.03 ALtima® Blaze Straight 31.00 122.64
.3750 180X3754B 18919 3/8 3/8 4 2-1/2 0.03 ALtima® Blaze Straight 37.00 139.05
.5000 180L5000B 18916 1/2 1/2 4 2 ALtima® Blaze Straight 121.00 154.47
.5000 180X5000B 18918 1/2 1/2 5 3 ALtima® Blaze Straight 13.00 193.11
.5000 180L5000BW 14820 1/2 1/2 4 2 ALtima® Blaze Weldon 30.00 159.55
.5000 180L5004B 18921 1/2 1/2 4 2 0.03 ALtima® Blaze Straight 35.00 169.91
.5000 180X5004B 18923 1/2 1/2 5 3 0.03 ALtima® Blaze Straight 4.00 212.42
.625 180X6254B 18927 .625 .625 6.00 3.00 ALtima® Blaze Straight 61.00 397.12
.6250 180L6250B 18920 5/8 5/8 5 2-1/4 ALtima® Blaze Straight 44.00 276.08
.6250 180X6250B 18922 5/8 5/8 6 3 ALtima® Blaze Straight 15.00 361.01
.6250 180L6254B 18925 5/8 5/8 5 2-1/4 0.03 ALtima® Blaze Straight 28.00 303.68
.6250 180L6258B 15895 5/8 5/8 5 2-1/4 0.125 ALtima® Blaze Straight 3.00 303.68
.6250 180XS6256B 15896 5/8 5/8 5 3 0.06 ALtima® Blaze Straight 10.00 397.12
.6250 180L6254BW 18103 5/8 5/8 5 2-1/4 0.03 ALtima® Blaze Weldon 2.00 310.09
.7500 180L7500B 18924 3/4 3/4 5 2-1/4 ALtima® Blaze Straight 49.00 389.7
.7500 180X7500B 18926 3/4 3/4 6 3 ALtima® Blaze Straight 73.00 472.29
.7500 180L7500BW 14826 3/4 3/4 5 2-1/4 ALtima® Blaze Weldon 0.00 396.11
.7500 180L7504B 18929 3/4 3/4 5 2-1/4 0.03 ALtima® Blaze Straight 39.00 428.66
.7500 180X7504B 18931 3/4 3/4 6 3 0.03 ALtima® Blaze Straight 85.00 519.52
1.0000 180L1000B 18928 1 1 5 2-1/4 ALtima® Blaze Straight 24.00 540.73
1.0000 180X1000B 18930 1 1 6 3 ALtima® Blaze Straight 34.00 652.93
1.0000 180L1004B 18933 1 1 5 2-1/4 0.03 ALtima® Blaze Straight 6.00 594.8
1.0000 180X1004B 18935 1 1 6 3 0.03 ALtima® Blaze Straight 21.00 718.22
1.0000 180L1000BW 17239 1 1 5 2-1/4 ALtima® Blaze Weldon 0.00 548.38
